JTAG-Booster for Analog Devices ADSP-21xxx
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
The initialization file JTAG060.INI was found in the current directory.
The target identification line of the initialization file is printed here.
The resulting I/O-address of the parallel port is printed here.
A JTAG-Booster is found on the parallel port
The JTAG chain is analyzed. There may be several parts in the JTAG
chain. The chain is analyzed and all parts except the Analog Devices
ADSP-21060/21061/21062 are switched to bypass mode.
The Analog Devices ADSP-21xxx does not have an ICODE register.
The length of all instruction registers in the JTAG chain are added.
The position of the Analog Devices ADSP-21xxx in the JTAG chain is
assumed to be zero, if not specified in the command line (see option
/CPUPOS=).
The position of the JTAG instruction register of the Analog Devices ADSP-
21xxx is assumed to be zero, if not specified in the command line (see
option /IROFFS=).
(10) The real length of the boundary scan register is displayed here and
compared with the boundary scan register length of a Analog Devices
ADSP-21060/21061/21062. This is very important, because the Analog
Devices ADSP-21060/21061/21062 does not have an IDCODE register.
(11) One Flash-EPROM AMD 29F010 selected with BMS# was found.
(12) The resulting data bus size is printed here.
(13) In this example one block must be erased.
10
JTAG_ADSP-21xxxa.doc
